HSS die for Whitworth thread cutting BSW DIN 223 - UT 10 FW

echoENGSKU: 309_001_UT 10 FW (00-15)___309_001_UT 10 FW00

nome_variante: Misura x Passo
variante_1: 1/8” x 40 - UT 10 FW00
Price:
Sale priceDhs. 4.00
Availability : 92

Description

HSS die for Whitworth thread cutting BSW, DIN 223.



Model UT 10 FW00 Specifications:

Size                             Inches 1/8"

Pitch                            TPI       40

External Diameter        mm       20

Thickness                    mm       5



Model UT 10 FW01 Specifications:

Size                             Inches 1/4"

Pitch                            TPI       20

External Diameter        mm       20

Thickness                    mm       7



Model UT 10 FW02 Specifications:

Size                             Inches 3/8"

Pitch                            TPI       16

External Diameter        mm       30

Thickness                    mm       11



Model UT 10 FW03 Specifications:

Size                             Inches 1/2"

Pitch                            TPI       12

External Diameter        mm       38

Thickness                    mm       14



Model UT 10 FW04 Specifications:

Size                             Inches 5/8"

Pitch                            TPI       11

External Diameter        mm       45

Thickness                    mm       18



Model UT 10 FW05 Specifications:

Size                             Inches 3/4"

Pitch                            TPI       10

External Diameter        mm       45

Thickness                    mm       18



Model UT 10 FW06 Specifications:

Size                             Inches  7/8"

Pitch                            TPI       9

External Diameter        mm       55

Thickness                    mm       22



Model UT 10 FW07 Specifications:

Size                             Inches  1"

Pitch                            TPI       8

External Diameter        mm       55

 Thickness                    mm      22



Model UT 10 FW08 Specifications:

Size                             Inches  1-1/8"

Pitch                            TPI       7

External Diameter         mm      65

Thickness                    mm       25



Model UT 10 FW09 Specifications:

Size                             Inches 1-1/4"

Pitch                            TPI       7

External Diameter        mm      65

Thickness                    mm      25



Model UT 10 FW10 Specifications:

Size                             Inches 1-3/8"

Pitch                            TPI       6

External Diameter        mm      65

Thickness                    mm      25



Model UT 10 FW11 Specifications:

Size                             Inches 1-1/2"

Pitch                            TPI       6

External Diameter        mm      75

Thickness                    mm      26



Model UT 10 FW12 Specifications:

Size                             Inches 1-5/8"

Pitch                            TPI       5

External Diameter        mm      75

Thickness                    mm      26



Model UT 10 FW13 Specifications:

Size                             Inches 1-3/4"

Pitch                            TPI       5

External Diameter        mm      90

Thickness                    mm      27



Model UT 10 FW14 Specifications:

Size                             Inches 1-7/8"

Pitch                            TPI       4-1/2

External Diameter         mm      90

Thickness                    mm      27



Model UT 10 FW15 Specifications:

Size                             Inches  2

Pitch                            TPI       4-1/2

External Diameter        mm      90

Thickness                    mm      27
